Rotary / Semi-Rotary Label Die Cutting Machine

The ZM-320 rotary/semi-rotary label die-cutting machine is a newly-developed converting machine equipped with inline slitter. This machine adopts latest Rexrtoh-Bosch (Germany) servo and control system, including unwinder, web-guider, lamination, registered die-cutter, slitter and rewinder.

The die-cutter is our patent product, and it can be either full rotary or semi-rotary according to the specific production requirement. When the die-cutter is semi-rotary, the tension among unwinder, web-guider and rewinder will be the same (different from traditional intermittent type), and the material will not run away during the die-cutting process. Semi-rotary die-cutting unit adopts one big magnetic cylinder. If you have different applications, the only job is to change the flexible die.

Characteristics
ZM-320 rotary/semi-rotary label die-cutting machine has the characteristics of fast speed, super accuracy, easy operation, high efficiency and less cost. It’s good for all kinds of label die-cutting jobs, including short run and long run printing jobs.

If the printing quantity is large, you can change the magnetic roller accordingly. By using our rotary/semi-rotary label die-cutting machine, the die-cutting quality and output will be highly increased.

Specifications
Max die-cutting speed (rotary): 120m/min
(semi-rotary): 65m/min
Max die-cutting length (rotary): 190.5-539.75mm
(semi-rotary): 100-350mm
Max die-cutting width: 300mm
Max web width: 320mm
Max unwinder dia.: 600mm
Max. rewinder dia.: 600mm
Die-cutting accuracy: +-0.1mm
Slitting width: 20-300mm

Our ZM-320 rotary/semi-rotary label die-cutting machine commits to make the maximum profit for you. It’s an ideal converting machine for the printing house.
